Node Wire Architecture

The Node Wire platform is designed as a three-layer Python platform that runs connector adapters over REST, gRPC, or MCP. Each connector talks to an external system (e.g., Google Drive, SMTP, Stripe); the runtime provides a consistent execution contract, error handling, and resilience.

This page is the overview. The detail lives on the topic pages. Read them in this order (the reading map has the whole path):

Page Answers
This page What the three layers are, and how a request moves through them
Domain What connector, action, ConnectorResponse, ErrorCategory, tenant pin and named config mean
Seams Where the layers hand off: ConnectorFactory, invoke.py, PolicyHook, SecretProvider, AuthProvider, ErrorMapper
The run() pipeline What happens to every action, in order
Tenancy Tenant resolution, entitlement, tenant secrets, MCP tenant tools
Bindings How an action becomes a REST route, an MCP tool and a gRPC method

High-Level Architecture

The platform is split into three layers:

  • Layer A – Runtime (src/node_wire_runtime/): The engine that every connector runs inside. It defines the execution contract, a standard error taxonomy, retries and circuit breaking, and telemetry.
  • Layer B – Connectors (src/node_wire_<connector>/): Adapters that implement that contract and call external systems (HTTP Generic, SMTP, Stripe, Google Drive, FHIR Epic, FHIR Cerner, Salesforce, Slack). Each connector has its own input/output schema and business logic.
  • Layer C – Bindings (src/bindings/): How the platform is exposed to the outside world—REST API, gRPC server, MCP server—and ConnectorFactory, which builds tenant-pinned connector instances. The factory reads config/connectors.yaml at startup (an external input, not part of the layer) and bootstraps it into the runtime ConnectorConfigStore (Layer A).

External callers reach the platform over REST, gRPC, or MCP. Each binding adapter resolves transport-specific tenant and caller identity, then hands off to the shared invoke seam.

flowchart TB
    subgraph input["Deployment input · outside the layers"]
        Config[/"config/connectors.yaml<br/>or NW_CONFIG_PATH"/]
    end

    subgraph layerC["Layer C · Bindings · src/bindings/"]
        RestAPI["REST API<br/>FastAPI :8000"]
        GrpcSrv["gRPC server<br/>:50051"]
        McpSrv["MCP server<br/>stdio · HTTP"]
        Invoke["invoke.py · shared seam<br/>exposure → factory.get → normalize"]
        Factory["ConnectorFactory"]
    end

    subgraph layerA["Layer A · Runtime · src/node_wire_runtime/"]
        Store[("ConnectorConfigStore<br/>per-tenant configs")]
        Run["BaseConnector.run<br/>validate → policy → resilience → error mapping"]
    end

    subgraph layerB["Layer B · Connectors · src/node_wire_*/"]
        Pkg["Package per connector<br/>schema.py · discriminated union<br/>logic.py · class + error_map<br/>normalizers.py · optional"]
        Actions["Connector class · BaseConnector or RestConnector<br/>@sdk_action / @nw_action / action_specs"]
        Shipped["Shipped connectors<br/>google_drive · smtp · stripe · http_generic<br/>salesforce · slack · fhir_epic · fhir_cerner"]
    end

    Ext[["External systems · third-party APIs"]]

    RestAPI -- "tenant: header / JWT" --> Invoke
    GrpcSrv -- "tenant: metadata" --> Invoke
    McpSrv -- "tenant: session / pin" --> Invoke
    Invoke -- "1 · get(tenant, config)" --> Factory
    Invoke -- "2 · run() → ConnectorResponse" --> Run
    Config -. "read by load()" .-> Factory
    Factory -- "load(): bootstrap __default__<br/>get(): resolve config" --> Store
    Factory -. "builds tenant-pinned instance<br/>injects SecretProvider · AuthProvider · PolicyHook" .-> Run
    Run -- "internal_execute" --> Actions
    Actions --> Ext
    Run ~~~ Pkg
    Run ~~~ Shipped

    classDef binding fill:#ddf1fb,stroke:#1a88b0,stroke-width:1px,color:#0d2f3d
    classDef store fill:#f2f4f7,stroke:#8a9bac,stroke-width:1px,color:#1c2733
    classDef runtime fill:#fdf2d6,stroke:#b8860b,stroke-width:1px,color:#3a2c05
    classDef connector fill:#fde2ea,stroke:#b81548,stroke-width:1px,color:#3d0a1d
    classDef ext fill:#ddf5f0,stroke:#12867a,stroke-width:1px,color:#0b2f2a
    class RestAPI,GrpcSrv,McpSrv,Invoke,Factory binding
    class Config store
    class Store,Run runtime
    class Actions,Pkg,Shipped connector
    class Ext ext
    style input fill:#f7f8fa,stroke:#8a9bac,stroke-width:1px,stroke-dasharray:4 3,color:#1c2733
    style layerC fill:#f4fbfe,stroke:#1a88b0,stroke-width:1px,color:#0d2f3d
    style layerA fill:#fffaf0,stroke:#b8860b,stroke-width:1px,color:#3a2c05
    style layerB fill:#fff5f8,stroke:#b81548,stroke-width:1px,color:#3d0a1d

Request lifecycle

%%{init: {"sequence": {"actorMargin": 28, "width": 110, "boxMargin": 6, "noteMargin": 6, "messageMargin": 28}}}%%
sequenceDiagram
    autonumber
    participant C as Client
    participant B as Binding
    participant I as invoke.py
    participant R as run()
    participant X as Connector

    C->>B: request
    Note over B: resolve tenant<br/>+ config
    B->>I: invoke(id, action, payload)
    Note over I: exposure check<br/>factory.get<br/>normalize args
    I->>R: run(payload, scopes)
    Note over R: validate → policy<br/>→ resilience
    R->>X: internal_execute
    X->>X: outbound call
    X-->>R: result / exception
    Note over R: ErrorMapper
    R-->>I: ConnectorResponse
    I-->>B: ConnectorResponse
    B-->>C: encoded response

A failure anywhere in run is mapped by ErrorMapper into the same ConnectorResponse envelope with an ErrorCategory — bindings translate that to an HTTP status, a gRPC code, or an MCP tool error, but the connector contract is identical on all three.

Layer A – runtime

Purpose: Provide shared execution and reliability so every connector behaves in a consistent way (validation, errors, retries, telemetry) without each connector reimplementing the same plumbing.

Location: src/node_wire_runtime/

Main Components

  • BaseConnector: Abstract base class for all connectors. It owns the run() pipeline below.
  • ConnectorResponse / ErrorCategory / ErrorMapper: the response envelope, the error taxonomy (RETRYABLE, BUSINESS, AUTH, FATAL), and the per-connector exception mapping. See Domain.
  • Resilience: retries (Tenacity) and the runtime's own circuit breaker, which counts only upstream-health failures, once per invocation.
  • PolicyHook, SecretProvider, AuthProvider: pluggable seams the factory injects. See Seams.
  • ConnectorConfigStore and tenant pinning: per-tenant named configs, and instances bound to one tenant. See Tenancy.
  • Telemetry: OpenTelemetry integration for tracing.

The run() pipeline

Every action goes through the same sequence. The tenant pin is checked before the trace span opens; everything after it runs inside the span.

flowchart TB
    In(["run(payload)"]) --> Pin["tenant pin check"]
    Pin --> Val
    Pin -. "TENANT_MISMATCH" .-> Err

    Val["Pydantic validation<br/>discriminated union on action"]
    Pol["PolicyHook · allow / deny<br/>always set on factory instances"]
    Res["Retries + circuit breaker<br/>Tenacity · circuit breaker"]
    Exec["internal_execute<br/>dispatch to Layer B"]
    Val --> Pol --> Res --> Exec
    Otel(["OpenTelemetry span"]) -. "wraps validate → error mapping" .-> Val

    Err["ErrorMapper<br/>stable code + ErrorCategory"]
    Pol -. "PolicyDenied" .-> Err
    Res -. "exception" .-> Err
    Exec --> Out(["ConnectorResponse"])
    Err --> Out

    classDef step fill:#fdf2d6,stroke:#b8860b,stroke-width:1px,color:#3a2c05
    classDef term fill:#eceff3,stroke:#5b7387,stroke-width:1px,color:#1c2733
    classDef err fill:#fde2ea,stroke:#b81548,stroke-width:1px,color:#3d0a1d
    class Pin,Val,Pol,Res,Exec step
    class In,Out term
    class Err err
    class Otel term

Layer B – connectors

Purpose: System adapters that talk to external services. Each connector defines input/output models and declares its actions with @sdk_action (or its alias @nw_action) or action_specs. Connectors do not implement internal_execute — BaseConnector.internal_execute dispatches to the declared action. Hand-written connectors subclass BaseConnector; OpenAPI-generated ones subclass RestConnector. ConnectorFactory injects the tenant-scoped SecretProvider, AuthProvider(s), and PolicyHook when it builds an instance.

Location: src/node_wire_<name>/

Common Structure

  • schema.py: Pydantic models for request and response.
  • logic.py: Connector class and external service logic, including an optional error_map class attribute that registers the connector's exception mappings — scoped to that connector's own connector_id so they can never be resolved for another connector's errors.
  • normalizers.py (optional): MCP argument normalizers that map LLM aliases to canonical fields before run() (wired via mcp_normalize on the action).

Layer C – bindings

Purpose: Expose connectors over different protocols and build tenant-pinned connector instances from configuration (read from config/connectors.yaml, held in the runtime config store).

Location: src/bindings/

Binding invoke

REST, MCP, and gRPC share one invoke seam in src/bindings/invoke.py (Seams — invoke.py). Transport-only concerns stay in each binding.

Bindings Offered

  • REST API (FastAPI): Dynamic routes at POST /connectors/{connector_id}/{action}.
  • gRPC Server: Protocol buffers based interface on port 50051.
  • MCP Server: Model Context Protocol implementation for AI agents.

What each binding does to arguments and errors: Connectors on REST, MCP and gRPC.
